Ready Made Shipping Container Homes for Sale
These units are fabricated from ISO‑grade 1C‑trip steel containers that have been cut, reinforced, and fitted with insulated wall panels, roof systems, and pre‑installed service conduits. The base structure retains the original container’s corner castings and locking mechanisms, which provide proven stacking strength and transport compatibility.
Structural Specifications
| Parameter | Typical Value |
|---|---|
| External dimensions (L × W × H) | 6058 mm × 2438 mm × 2591 mm (20 ft) or 12192 mm × 2438 mm × 2591 mm (40 ft) |
| Wall panel thickness (insulated) | 100 mm mineral wool core with 0.5 mm steel skins |
| Roof load capacity (uniform) | 1.5 kN/m² (design for snow & equipment) |
| Floor load capacity (uniform) | 3.0 kN/m² (suitable for office furniture, light machinery) |
| Corner casting rating | ISO 1161, 20 tonne stacking capacity |
Insulation and Envelope Performance
Wall assemblies achieve a nominal U‑value of 0.28 W/(m²·K) when the mineral wool core is installed at 100 mm thickness, meeting energy‑efficiency criteria for temporary office and accommodation modules in climate zones 3‑5. Roof panels incorporate a reflective foil layer that reduces solar gain by up to 40 % under direct sunlight.
Air leakage is limited to 0.5 L/(s·m²) at 75 Pa pressure differential, verified through factory blower‑door tests on representative samples. This level minimizes heating load fluctuations in remote site applications where external power may be intermittent.
Modular Connection Systems
Units are equipped with factory‑welded steel brackets that accept standard twist‑lock couplers, enabling vertical stacking of up to three containers without additional shoring. Horizontal interconnection uses bolted gusset plates with M20 high‑strength fasteners, providing a shear capacity of 150 kN per joint.
Service chases for electrical, data, and HVAC conduits are pre‑drilled at 100 mm intervals along the interior wall studs, allowing rapid pull‑through of cables and pipes after placement. All chase openings are fitted with removable steel covers that maintain the enclosure’s fire rating.
Factory Fabrication Process
Each container undergoes shot‑blasting to Sa 2.5, followed by a two‑coat epoxy‑primer system (total dry film thickness 120 µm) before insulation installation. Interior finishes consist of 12 mm gypsum board with a vapor‑ retarder backing, taped and jointed to achieve a Class A flame spread rating.
Electrical rough‑in includes PVC‑sheathed THHN conductors sized for 20 A branch circuits, routed to a main distribution panel rated at 100 A, 3‑phase. Plumbing provisions feature PEX‑A lines for hot and cold water, stubbed to 15 mm fixtures with shut‑off valves accessible from the interior.
Applications in Industrial and Remote Sites
Because the units retain ISO corner fittings, they can be transported on standard chassis and off‑loaded with conventional cranes, making them suitable for construction‑site offices, mining camp accommodations, and disaster‑relief housing where ground preparation is minimal.
The insulated envelope reduces the need for external cladding in temperate climates, while the steel structure provides inherent resistance to impact and vandalism, a key consideration for temporary installations in high‑traffic zones.
Customization Options
- Exterior cladding: corrugated steel panels, fiber‑cement boards, or insulated metal panels with selectable R‑values up to 4.0 m²·K/W.
- Window systems: double‑glazed low‑e units with thermally broken aluminum frames, operable or fixed, sized to meet egress requirements.
- Interior partitions: demountable steel stud walls with acoustic infill, allowing reconfiguration of floor area.
- Energy packages: solar‑ready roof mounting, battery‑inverter kits, or connection to external generator feeds.
- HVAC: packaged rooftop units or split‑system heat pumps with ductwork pre‑routed to ceiling diffusers.
Quality Assurance and Testing
Dimensional verification is performed on each unit using laser‑tracked measurement stations, confirming that critical interfaces (corner castings, door frames, service chases) remain within ±2 mm of design tolerances.
Thermal performance is validated by hot‑box testing on representative wall assemblies, with results documented in a test report available upon request. Fire resistance of interior finishes is assessed according to ASTM E84, yielding a flame spread index ≤25.
Final inspection includes a functional check of all installed services: continuity testing of power circuits, pressure testing of water lines to 600 kPa, and verification of HVAC airflow rates against design specifications.
Frequently Asked Questions
Can dimensions be customized beyond standard 20 ft and 40 ft lengths?
Length adjustments are achievable by cutting and welding additional ISO‑grade sections, though this affects corner‑casting alignment and may require supplemental reinforcement plates. Such modifications are evaluated on a case‑by‑case basis.
What information is required before a quotation can be issued?
To generate a technical quote we need the intended use (office, accommodation, control room), required interior finish level, climate zone for insulation selection, and any special service loads (e.g., 3‑phase power, compressed air).
How are units protected during export shipment?
Each finished container is wrapped in UV‑stabilized polyethylene shrink film, secured with steel banding, and placed on a flat‑rack or container chassis with corner‑protectors to prevent impact damage during transit.
Next Steps
For a detailed technical proposal, including load‑calculation drawings, insulation performance data, and lead‑time estimates, please contact our engineering team. Provide your project specifications and we will respond with a customized quotation and applicable compliance documentation.
